Other
1 YEAR
Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Video technical support, Online support, Spare parts, Field maintenance and repair service
None
None
New
Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles
Film, Case
Plastic, Metal, Wood
Automatic
Electric
220V/380V/440V
8kw-18kw
Hebei, China
XINGLONG
10-20T
CE & ISO
High Safety Level
Engineers available to service machinery overseas
Multi Color
150+pcs/min
automatic printing slotting die cutting machine
making carton
carton box
FAY1224
automatic
Automatic flexo printing machine for carton box printing
lThe machine can finish multi processes one time such as: printing, slotting, creasing, trimming, corner cutting, punching,die cutting and so on.
lMachine is designed according to high request and reliable function, humanization operation, it can setting, revision, implement, changing and memories in short time, and display data accurately .
Main Technology parameters
Model | YJ150-1022 | YJ130-1224 | YJ120-1426 |
Machine inside width (mm) | 2400 | 2600 | 2800 |
Max feeding paper siz(mm) | 1000*2200mm | 1200mm*2400mm | 1400*2600mm |
Max effective printing size(mm) | 1000*2000mm | 1200mm*2200mm | 1400*2400mm |
Min coverage size(mm) | 350*700mm | 350mm*700mm | 350mm*700mm |
Design speed (pcs/min) | 150pcs/min | 130pcs/min | 120pcs/min |
Working speed (pcs/min) | 130pcs/min | 120pcs/min | 100pcs/min |
Standard Thickness of printing plate | 6mm | 6mm | 6mm |
Printing precision | ±0.5mm | ±0.5mm | ±0.5mm |
Thickness of cardboard | 1.2-9mm | 1.2-9mm | 1.2-9mm |
Wall thickness | 40mm | 40mm | 40mm |
Main motor power | About :15kw | About :15kw | About :15kw |
Automatic flexo printing machine for carton box printing
lThe machine can finish multi processes one time such as: printing, slotting, creasing, trimming, corner cutting, punching,die cutting and so on.
lMachine is designed according to high request and reliable function, humanization operation, it can setting, revision, implement, changing and memories in short time, and display data accurately .
Main Technology parameters
Model | YJ150-1022 | YJ130-1224 | YJ120-1426 |
Machine inside width (mm) | 2400 | 2600 | 2800 |
Max feeding paper siz(mm) | 1000*2200mm | 1200mm*2400mm | 1400*2600mm |
Max effective printing size(mm) | 1000*2000mm | 1200mm*2200mm | 1400*2400mm |
Min coverage size(mm) | 350*700mm | 350mm*700mm | 350mm*700mm |
Design speed (pcs/min) | 150pcs/min | 130pcs/min | 120pcs/min |
Working speed (pcs/min) | 130pcs/min | 120pcs/min | 100pcs/min |
Standard Thickness of printing plate | 6mm | 6mm | 6mm |
Printing precision | ±0.5mm | ±0.5mm | ±0.5mm |
Thickness of cardboard | 1.2-9mm | 1.2-9mm | 1.2-9mm |
Wall thickness | 40mm | 40mm | 40mm |
Main motor power | About :15kw | About :15kw | About :15kw |
