Semi automatic stitching machine for making corrugated carton box

Semi auto stitching machine

The main parts and functions

★ Imported from Japan fuji series double servo drive, precision, reduce the mechanical transmission part, effectively reduce the mechanical fault rate.

★ Delta touch screen operation, the parameters (screw pitch, the number of nails, nail, tailgate) transform is convenient.

★ The whole control system adopts the control system of delta PLC, more accurately convey instructions.

★ After electric baffle, by Taiwan Liming stepper motor drive, accurate size, transform size more convenient.

★ The bottom die, tungsten steel blade adopts Japanese made (wear) has greatly increased the service life.

★ The whole group of nail head. All computer gongs are made of special steel, precision machining, imported from Taiwan, Italy.

★ You can nail a single nail, double nail, once completed, can be suitable for different customers for different requirements for the nail.

★ This transformation and adjustment of carton carton size from the nail it takes only a minute to be completed, greatly saves time and is convenient to operate.

★ The front feeding part automatically counting, the feeding table is provided with a photoelectric sensing device, automatic rising feeder.

★ This post with automatic counting function, finished cartons can be set according to the number (1-99) sub stack sent to lose.

★ Send machine end, easy to pack up and bound.

★ Nail automatic alarm after line. (to avoid the non linear when the leak to fight, less nail bad product).

★ From semi-finished stapled to the finished and packaged Banding placed in the whole process of only two people operation, the operation is simple and convenient for less pay.

Mechanical parameters:
