SF320-1800
xinglong
single face corrugating cardboard production line
Hebei,China
1 Year
Provided
New
Cartons
Easy to Operate
Customized
Ordinary Product
Provided
INSTRUCTON AND FEATURES
1.Paper feeding way is vacuum suction way and perfect flute formation in high speed production.
2. Available width:1400/1600/1800/2000/2200 mm
3. Flute type: A, B, C, D, E, F,G UV
4. corrugated roller:φ280/300/320/360/380mm
5. Drive using universal joints, isolate the vibration source which make transmission more stable, reliable.
6. Driven gearbox adopts immerse in lubrication oil, reduce noise, universal joint transmission. Separate structure is independent controlled and transmission more stable.
7. The glue coating part adopt automatic circulating glue feeding way (manual or electrical isolation device)
8. Pneumatic control to adjust the glue feeding and adjust gluing capacity electrically or manually; the glue parts running separately while the main motor stopped, prevent paste from drying up.
9. It is equipped with the high pressure powerful air fan with the wind capacity adjustable device and silencer; air source and electric control are in one cabinet
10. The machine wall made by cast iron and thickness 130mm
11. The corrugated roller materials 50CrMo alloy, the inner hole is fine bored, tempered and finish turned and the surface is medium-frequency quenched, CNC polished and fine grinded and hard chrome-plated.
12. The corrugated roller diameter ¢320mm; Hardness can reach more than HRC60 which ensures good wear-resistance and long life service.
TECHNOLOGY PARAMETERS
Model | SF320-1800 |
Working width | 1800 mm |
Heating way | Steam /oil/electric |
Flute type | A B C D E |
Operate direction | Left or right according to customer’s factory |
Designed speed | 120m/min |
Economic running speed | 100m/min |
Temperature range | 160—200℃ |
Steam pressure | 0.8—1.3Mpa |
Air source | 0.4—0.8Mpa |
COMPONENTS
Flute roller | Hebei Wansong |
Pressure roller | Hebei Wansong |
Preheater roller | Self-produced |
Other shaft | High quality seamless steal pipe |
Both sides wallboard | HT200 cast iron |
Main bearing | ZWZ and Hawaluo |
Chain and sprocket wheel | Zhejiang Baidun |
Frequency conversion motor | Hebei Dongli |
Walking motor | Zhejiang Dongbang |
Fan motor | Hengshui Yongshun |
Gluing pump motor | Hebei Dongli |
Air cylinder | Air TAC |
Frequency converter | Delta Taiwan |
Contactor | Chit |
INSTRUCTON AND FEATURES
1.Paper feeding way is vacuum suction way and perfect flute formation in high speed production.
2. Available width:1400/1600/1800/2000/2200 mm
3. Flute type: A, B, C, D, E, F,G UV
4. corrugated roller:φ280/300/320/360/380mm
5. Drive using universal joints, isolate the vibration source which make transmission more stable, reliable.
6. Driven gearbox adopts immerse in lubrication oil, reduce noise, universal joint transmission. Separate structure is independent controlled and transmission more stable.
7. The glue coating part adopt automatic circulating glue feeding way (manual or electrical isolation device)
8. Pneumatic control to adjust the glue feeding and adjust gluing capacity electrically or manually; the glue parts running separately while the main motor stopped, prevent paste from drying up.
9. It is equipped with the high pressure powerful air fan with the wind capacity adjustable device and silencer; air source and electric control are in one cabinet
10. The machine wall made by cast iron and thickness 130mm
11. The corrugated roller materials 50CrMo alloy, the inner hole is fine bored, tempered and finish turned and the surface is medium-frequency quenched, CNC polished and fine grinded and hard chrome-plated.
12. The corrugated roller diameter ¢320mm; Hardness can reach more than HRC60 which ensures good wear-resistance and long life service.
TECHNOLOGY PARAMETERS
Model | SF320-1800 |
Working width | 1800 mm |
Heating way | Steam /oil/electric |
Flute type | A B C D E |
Operate direction | Left or right according to customer’s factory |
Designed speed | 120m/min |
Economic running speed | 100m/min |
Temperature range | 160—200℃ |
Steam pressure | 0.8—1.3Mpa |
Air source | 0.4—0.8Mpa |
COMPONENTS
Flute roller | Hebei Wansong |
Pressure roller | Hebei Wansong |
Preheater roller | Self-produced |
Other shaft | High quality seamless steal pipe |
Both sides wallboard | HT200 cast iron |
Main bearing | ZWZ and Hawaluo |
Chain and sprocket wheel | Zhejiang Baidun |
Frequency conversion motor | Hebei Dongli |
Walking motor | Zhejiang Dongbang |
Fan motor | Hengshui Yongshun |
Gluing pump motor | Hebei Dongli |
Air cylinder | Air TAC |
Frequency converter | Delta Taiwan |
Contactor | Chit |
