RS-1500H Hydraulic Mill Roll Stand
IMPORTANT FEATURES
1.Working method: Hydraulic
2. Working width 工作幅宽: Max1600/1800/2000mm Min 600mm
3.Roll diameter 原纸直径: Max φ1500mm Min φ350mm
4. Single side max loading: 2.2 tons
5.Main bearing diameter of stand: 240mm
6. Speed :Suitable for 0-150m corrugated cardboard line
7.Air pressure : 0.6-0.9Mpa
8.Total power: 4.0kw
9.Voltage : 380v 50Hz (or depend on clients)
HYDRAULIC SYSTERM PAREMETER
1.Working pressure: 1.2-1.6Mpa
2.The diameter of oil cylinder (clamping): φ100mm×φ420mm ,φ63×φ760mm
3.Motor power of hydraulic unit: 4.0kw (continuous work)
4.working voltage of Hydraulic unit electromagnetic valve: :customize
STRUCTURE CHARACTERISTICS
1.Symmetrical structure can install two rolls of paper at the same time and continually change paper
2.Full hydraulic control paper roll damp, life-lower, loosen, clamp, left-right movement.
3.Adopts pneumatic tension to adjust basis paper tension
4. 4-point brake control paper tension, manual control, also can control tension with splicer together.
TECHNICAL PAREMETER
Working Width | 1800mm |
Max Roll diameter | 1500mm |
Min Roll diameter | 350mm |
Main Shaft Dia | Φ240mm |
Max. Supporting Weight (One side) | 2200kg |
MAIN COMPONENTS
expansion clamp | Hebei |
hydraulic cylinder | Shandong |
Main shaft | High quality seamless steal pipe |
Both sides wallboard and arm | HT200 cast iron |
Main bearing | Hawaluo |
Electric components | Chit |
