New product one year warranty box making semi-auto stapler machine

Availability:
Quantity:
  • Other

  • Manufacturing Plant

  • New

  • Beverage, Commodity

  • Cartons

  • Paper

  • Semi-Automatic

  • Electric

  • 3ph 380v 50hz

  • 5KW

  • Hebei, China

  • 2000kg

  • 2800*2600*1900mm

  • CE

  • computer set size and order

  • New product one year warranty box making semi-auto stapler machine

  • box stitching

  • Pin head from Taiwan

  • servo motor

  • computer control

  • 2400, 2600, 3000

  • YASKAWA

  • DELTA

  • DELTA

  • Engineers available to service machinery overseas

New product one year warranty box making semi-auto stapler machine





Product Description

Performance

1. Adopts Japanese servo mechanism and Taiwan touch screen

2. Rubber wheel be adjusted by motorized, easy to adjust, more personal

3. Single/, double// and strengthen nail // /  / // are available, be finished one time, it can meet different requirements of different clients.

It can change size only one minute, fast, needn’t experience.

4. Feeding part automatically counting, sending and bundling.Human-machine operation panel, easy to operate, display the trouble locate and easy for maintenance.

 5. Automatic alarm when nail is over. (to avoid nail sick or less nail).

7. Only need two operators from semi-produce making to final products assortment consequently reducing cost of human resources and easy to operate.

Technology Parameters:

Model

2400

Max sheet size

1500×2400mm

Speed

450pin/mint

Min sheet size

300×606mm

Nail Span

30-100mm(adjustable)

Total Power

5kw

Number of nail

1-99pin

Feeding height

900mm

Nail type

Single, double and reinforced nail

Machine size

2800mm*2600mm

nail line specification

2.0mm×(0.65-0.75mm)

Weight

2000KGS

Packaging & Shipping

Customers

FAQ


1. Q: Are you a manufacturer, trading company or third party?

A: We are a manufacturer, located in Dongguang county, Hebei province, China.

Warmly welcome to visit our company

2. Q: What is your minimum order quantity, can you send me samples?

A: Our minimum quantity is 1 set, as our product is machinery equipment, it is difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.


3. Q: How does your factory do regarding quality controlling?

A: 1) All raw material we used are environmental-friendly

2) Skillful workers care every details in handling the producing and packing process

3) Quality control department are specially responsible for quality in each process

We have been kept providing high quality products by introducing advanced technologies for over 20 years, and our products are also widely exported to many different countries including Russia, the middle east, Africa, Southeast Asia, EU, etc. Which earned us a high reputation among the customers.


4. Q: How about the after-sale service?

A: 1) TM online 24 hours, also contact by email, skype, wechat, whatsapp, etc.

2) To solve the problems with videos/pictures

3) One year warranty for spare parts change.
