xinglong
Automatic splicers
New
China,Hebei
1 Year
1 Year
Easy to Operate
High speed
Customized
Ordinary Product
Provided
High speed automatic splicers
Structural Feature:
★The maximum diameter of the applicable paper：1500mm。
★Paper planes with automatic tension control, high-speed bin, high success rate。
★No tail paper receiving, reducing paper consumption (only partially overlapping paper tape with a width of 40mm).
★when paper car take out, the automatic turn out, and the vacuum adsorption, easy paper loading, automatic tension control paper receiving zero turnovers.
★All PLC automatic control, accurate, less failure, easy maintenance.
★The first round of the buffer when you pull the paper, automatic alignment, easy to pull paper.
★Machine superiority cylinder control speed splicers paper receiving moment does not appear normal motor control of rubble, blistering。
★paper receiving highest speed of 200 m / min.
Technical Parameters:
Effective width | 1800/2000/2200mm |
Operation direction | left or right（determined in accordance with customer plant） |
The highest speed | 200m/min |
Working speed pressure： | 0-200m/min 6bpa |
Single machine weight | max 2300Kg |
Speed:
Paper weight（g/㎡) | Surface paper speed（m/min)
| Flute paper speed（m/min)
|
70~90 | 120 | 100 |
90~110 | 150 | 130 |
110~130 | 200 | 160 |
Over 130 | 250 | 200 |
High speed automatic splicers
Structural Feature:
★The maximum diameter of the applicable paper：1500mm。
★Paper planes with automatic tension control, high-speed bin, high success rate。
★No tail paper receiving, reducing paper consumption (only partially overlapping paper tape with a width of 40mm).
★when paper car take out, the automatic turn out, and the vacuum adsorption, easy paper loading, automatic tension control paper receiving zero turnovers.
★All PLC automatic control, accurate, less failure, easy maintenance.
★The first round of the buffer when you pull the paper, automatic alignment, easy to pull paper.
★Machine superiority cylinder control speed splicers paper receiving moment does not appear normal motor control of rubble, blistering。
★paper receiving highest speed of 200 m / min.
Technical Parameters:
Effective width | 1800/2000/2200mm |
Operation direction | left or right（determined in accordance with customer plant） |
The highest speed | 200m/min |
Working speed pressure： | 0-200m/min 6bpa |
Single machine weight | max 2300Kg |
Speed:
Paper weight（g/㎡) | Surface paper speed（m/min)
| Flute paper speed（m/min)
|
70~90 | 120 | 100 |
90~110 | 150 | 130 |
110~130 | 200 | 160 |
Over 130 | 250 | 200 |
