1800
xinglong
Single facer group
China,Hebei
New
China,Hebei
Provided
Electric
Customized
1 Year
Provided
Making corrugated paper
Single Facer Group
SF280-1800 single Facer Machine
Features
Paper feeding way is vacuum suction way and perfect flute formation in high speed production.
Available width:1400/1600/1800/2000/2200 mm
Flute type: A, B, C, D, E, F, UV
Corrugated roller:φ280/300/320/360/380mm
Drive using chain drive
The glue coating part adopt automatic circulating glue feeding way (manual or electrical isolation device)
Pneumatic control to adjust the glue feeding and adjust gluing capacity electrically or manually; the glue parts running separately while the main motor stopped, prevent paste from drying up.
Configurations
Electric adjust the glue width.
It is equipped with the high pressure powerful air fan with the wind capacity adjustable device and silencer; air source and electric control are in one cabinet, operating side all with cover.
The machine wall made by cast iron and thickness 130mm
The corrugated roller materials 50CrMo alloy, the inner hole is fine bored, tempered and finish turned and the surface is medium-frequency quenched, CNC polished and fine grinded and hard chrome-plated.
The corrugated roller diameter ¢280mm; Hardness can reach more than HRC60 which ensures good wear-resistance and long life service.
Stainless steel glue tank with bottom inlet and outlet.
All geared used to be flame hardened 45 alloy steel.
Main variable frequency drive is DELTA brand.Electric component CHINT brand. The electromagnetic valve AIRTAC brand,Bearing HaWaLuo brand.
Parameters
Model | SF280-1800 |
Working width | 1800mm |
Heating way | Electric |
Flute type | Customize |
Operate direction | Left or right according to customer's factory |
Designed speed | 50m/min |
Economic running speed | 0-40m/min |
Temperature range | 160-200℃ |
Steam pressure | 0.8-1.3Mpa |
Air source | 0.4-0.8Mpa |
Electric shaftless mill roll stand
Features:
Electric drive
Symmetrical structure can install two rolls of paper at the same time and continually change paper roll;
It adopts motorized control clamping, loosen, up-down, movement, contraposition, translation .
Equipment was made of HT200-wide casting
It adopts pneumatic braking.
Electrical components are controlled centralized(domestic brand)
Technology Parameter:
Max working width | 1800 |
Min working width | 600mm |
Max paper roll diameter | 1500mm |
Single side carriage | 1500kg |
Air pressure | 0.6-0.9Mpa |
Power | 4.5kw |
Speed | 0-100m/min |
Paper sheet cutter (normal type)
Features:
YGQ series of reel paper sheet cutter mainly used for cutting reel paper or single wall paperboard to required size vertical and horizontal. It has characteristics of easy structure, convenience adjustment, long service life.
Technology parameters
Parameter | Unit | 1400 Model | 1600 Model | 1800 Model |
Max cutting width | mm | 1400 | 1600 | 1800 |
Cutting length range | mm | 400-2400 | 400-2400 | 400-2400 |
Cutting times | Times/min | 0-70 | 0-70 | 0-70 |
Stepless convertor | P3 | P3 | P3 | |
Motor | kw | 4.0 | 4.0 | 4.0 |
Working speed | m/min | 0-40 | 0-40 | 0-40 |
Paper weigth available | Gsm | 50-280 | 50-280 | 50-280 |
Weight | (approx) T | 1500kg | 1700kg | 1900kg |
Single Facer Group
SF280-1800 single Facer Machine
Features
Paper feeding way is vacuum suction way and perfect flute formation in high speed production.
Available width:1400/1600/1800/2000/2200 mm
Flute type: A, B, C, D, E, F, UV
Corrugated roller:φ280/300/320/360/380mm
Drive using chain drive
The glue coating part adopt automatic circulating glue feeding way (manual or electrical isolation device)
Pneumatic control to adjust the glue feeding and adjust gluing capacity electrically or manually; the glue parts running separately while the main motor stopped, prevent paste from drying up.
Configurations
Electric adjust the glue width.
It is equipped with the high pressure powerful air fan with the wind capacity adjustable device and silencer; air source and electric control are in one cabinet, operating side all with cover.
The machine wall made by cast iron and thickness 130mm
The corrugated roller materials 50CrMo alloy, the inner hole is fine bored, tempered and finish turned and the surface is medium-frequency quenched, CNC polished and fine grinded and hard chrome-plated.
The corrugated roller diameter ¢280mm; Hardness can reach more than HRC60 which ensures good wear-resistance and long life service.
Stainless steel glue tank with bottom inlet and outlet.
All geared used to be flame hardened 45 alloy steel.
Main variable frequency drive is DELTA brand.Electric component CHINT brand. The electromagnetic valve AIRTAC brand,Bearing HaWaLuo brand.
Parameters
Model | SF280-1800 |
Working width | 1800mm |
Heating way | Electric |
Flute type | Customize |
Operate direction | Left or right according to customer's factory |
Designed speed | 50m/min |
Economic running speed | 0-40m/min |
Temperature range | 160-200℃ |
Steam pressure | 0.8-1.3Mpa |
Air source | 0.4-0.8Mpa |
Electric shaftless mill roll stand
Features:
Electric drive
Symmetrical structure can install two rolls of paper at the same time and continually change paper roll;
It adopts motorized control clamping, loosen, up-down, movement, contraposition, translation .
Equipment was made of HT200-wide casting
It adopts pneumatic braking.
Electrical components are controlled centralized(domestic brand)
Technology Parameter:
Max working width | 1800 |
Min working width | 600mm |
Max paper roll diameter | 1500mm |
Single side carriage | 1500kg |
Air pressure | 0.6-0.9Mpa |
Power | 4.5kw |
Speed | 0-100m/min |
Paper sheet cutter (normal type)
Features:
YGQ series of reel paper sheet cutter mainly used for cutting reel paper or single wall paperboard to required size vertical and horizontal. It has characteristics of easy structure, convenience adjustment, long service life.
Technology parameters
Parameter | Unit | 1400 Model | 1600 Model | 1800 Model |
Max cutting width | mm | 1400 | 1600 | 1800 |
Cutting length range | mm | 400-2400 | 400-2400 | 400-2400 |
Cutting times | Times/min | 0-70 | 0-70 | 0-70 |
Stepless convertor | P3 | P3 | P3 | |
Motor | kw | 4.0 | 4.0 | 4.0 |
Working speed | m/min | 0-40 | 0-40 | 0-40 |
Paper weigth available | Gsm | 50-280 | 50-280 | 50-280 |
Weight | (approx) T | 1500kg | 1700kg | 1900kg |
