Hot Sale Single Facer Group for Making Cottugated Cardboard

Single Facer Group

(Single Facer Machine + Electric shaftless mill roll stand + sheet cutter)

SF 280-1800 Single Facer Machine

Features

1. Paper feeding way is vacuum suction way and perfect flute formation in high speed production.

2. Available width:1400/1600/1800/2000/2200 mm

3. Flute type: A, B, C, D, E, F, UV

4. corrugated roller:φ280/300/320/360/380mm

5. Drive using chain drive

6. The glue coating part adopt automatic circulating glue feeding way (manual or electrical isolation device)

7. Pneumatic control to adjust the glue feeding and adjust gluing capacity electrically or manually; the glue parts running separately while the main motor stopped, prevent paste from drying up.

• Configurations

1. Electric adjust the glue width.

2.It is equipped with the high pressure powerful air fan with the wind capacity adjustable device and silencer; air source and electric control are in one cabinet, operating side all with cover.

3. The machine wall made by cast iron and thickness 130mm

4. The corrugated roller materials 50CrMo alloy, the inner hole is fine bored, tempered and finish turned and the surface is medium-frequency quenched, CNC polished and fine grinded and hard chrome-plated.

5. The corrugated roller diameter ¢280mm; Hardness can reach more than HRC60 which ensures good wear-resistance and long life service.

6. Stainless steel glue tank with bottom inlet and outlet.

7. All geared used to be flame hardened 45 alloy steel.

8. Main variable frequency drive is DELTA brand.Electric component CHINT brand. The electromagnetic valve AIRTAC brand，Bearing HaWaLuo brand.

• Technology and Parameters

Electric shaftless mill roll stand

• Features:

1. Electric drive

2. Symmetrical structure can install two rolls of paper at the same time and continually change paper roll;

3. It adopts motorized control clamping, loosen, up-down, movement, contraposition, translation .

4. Equipment was made of HT200-wide casting

5. It adopts pneumatic braking.

6. Electrical components are controlled centralized(domestic brand)

• Technology Parameter:

 Normal Type Paper Sheet Cutter Machine

• Features


YGQ series of reel paper sheet cutter mainly used for cutting reel paper or single wall paperboard to required size vertical and horizontal. It has characteristics of easy structure, convenience adjustment, long service life.

• Technology and Parameters
