XL152-1000
xinglong
New
Electric
Automatic
Ordinary Product
Automatic partition slotter machine
Easy to Operate
High speed
1 Year
Customized
Provided
XL Automatic High-Speed Partition Slotter
1.Summary
XL Automatic high-speed partition slotter is
special equipment for carton clapboard, it is mainly
used to slot 3 ply 5ply corrugated cardboard and
hard paperboard. Feeding accurate, wide work
range and adjusting range, adaptable, efficient.
2.Technology parameter
| Model | XL104-900 | XL152-900 | XL152-1000 | XL152-1200 |
| Cutter die diameter | φ104 | φ152 | φ152 | φ152 |
| Max sheet size | 300*800mm | 450*900mm | 450*1000mm | 450*1200mm |
| Min sheet size | 100*100mm | 150*300mm | 150*300mm | 150*300mm |
| Min slot space | 40mm | 45mm | 45mm | 45mm |
| Slot width | 3-5mm | 3-5mm | 3-5mm | 3-5mm |
| Max slot depth | 150mm | 200mm | 200mm | 200mm |
| Max working speed | 100pcs/min | 80pcs/min | 80pcs/min | 80pcs/min |
| Thickness | 2-5mm | 2-5mm | 2-5mm | 2-5mm |
