ZXJ-2600
xinglong
ZXJ-2600 Semi-Automatic Folder&Gluer Machine
Function and Characteristics:
This machine is the last process equipment of the carton folding, it is used to combination of 3 and 5 layer corrugated cardboard production line( if need to glue 7 layer cardboard, we also can produce according customers’ appointed). Efficiency and production is attractive. The prominent advantage is low cost , strong adhesion, simple operating, saving labor and electric, runs smoothly, it is idea equipment for exporting advanced carton.
1. Working table
Photoelectric control the feeding, reduce labor and improve work efficiency.
2. Press correction
l After gluing and the second pressing to the bonder is smooth and firm.
l Equipped automatic correction device to make the carton size is correctly, and effectively avoid knife and fork phenomenon
l Fan airing function
l Counting output devices and with the photoelectric correlated mechanism, When reaching to the const carton, it outputs automatically.
3. Horizontal Output
Press counting output signal, then work automatically, stacking and strapping conviently.
4. Main spare parts
l Gear reducer is known brand from China
l Electricity components from “Chint”
l Conveyor belt is made in XINBEX
l PLC from Delta.
l The whold gluing head usd of imported material with finish process, wear-resisting, correction resisting, easy to clean.
Technology Parameter
Max size( length+ width) | 2400 |
Min size( length+ width) | 660 |
Max size（width+ height） | 1200 |
Min size( width+ height) | 250 |
Total Motor power | 2.54kw |
The length of Machine | 4500 |
The Width of Machine | 2100 |
The weight of Machine | 2000 |
Machine speed | 40 |
Dimension(mm) length×width×height | 4000×2000×1900 |
