xinglong
NC cut off machine double Helical Cross Cutter
Electric
Ordinary Product
China,Hebei
Provided
1 Year
1 Year
Provided
Easy to Operate
High quality
NC cut off macine with double Helical Cross Cutter
Product Description
Structure and Features:
Cutting length:500mm-9999mm. Cutting precision:±1mm.
Knife shaft gear using precision forging steel material high frequency quenching, lateral clearance transmission , adopt the keyless connection mode, high driving accuracy.
Helical knife structure,type sawtooth knife,decrease cutting obstruction,low noise.
Balance treatment, high quality alloy steel for blade shaft,which helps to keep it good stability.
Sun-shape wheels press cardboard in the front conveyer.The transporting is stable and with even pressure,which avoid jam caused or broken cardboard.
Precision adjustable gap gear, ensure blade precision engagement, running balance.
Machine base and wall panel adopt the grey cast iron, good rigidity, strong vibration resistance.
The servo controller control the servo motor, MCGS brand 10 inch touch screen
Technical parameter:
| Machine width (mm) | 1800/2000/2200 |
| Design speed (m/min) | 150 |
| Economy speed (m/min) | 100-150 |
| Cutting length (mm) | 500-9999 |
| Cutting precision (mm) | ±1 (even speed) |
| Total power | 25kw |
