Full Automatic laminator machine

Availability:
Quantity:
  • TMJ-1600A

  • xinglong

  • New

  • Full automatic laminator machine

  • Full Automatic

  • China,Hebei

  • Customized

  • Easy to Operate

  • Provided

  • Ordinary Product

  • 1 Year

  • Provided

封面(蓝)1

      Full Automatic Laminator

全自动贴面机

 FUNCTION AND CHARACTERISTICS

  1. Vacuum suction paper delivery system can accurately send paper into the machine; the circulating paper rack can not stop Put up the next batch of face paper to make it more efficient.

  2. The bottom paper is automatically by suction paper, which can be automatically synchronized according to the speed of manual surface paper.

  3. The new concept before the flexibility, high positioning accuracy, the bottom paper never ahead.

  4. The whole machine adopts the touch screen / PLC / servo motor control system, and the circuit system runs stably and can automatically display failure warning.

  5. Automatic glue supplement system, automatically supplement the loss amount of glue, and with the glue recycling, to avoid glue damage Waste consumption.

  6. The speed of the measuring roll line is designed scientifically to ensure the uniform amount of glue and avoid glue shaking during high-speed operation.

  7. Pressure roll unilateral adjustment, convenient and fast.

  8. The rocker controls the rise and fall of the washing stick, convenient to clean the lower roll of the rubber roller, convenient and fast cleaning.

  9. Humanized design counter to record your daily workload.Easy to do piece-rate work.

全自动贴面机1

Technology Parameter

Model TMJ-1300A TMJ-1450A TMJ-1600A

Maximum size

1300mm*1100mm
1450mm*1300mm 1600mm*1300mm
Minimum veneer size

400mm*400mm

400mm*400mm

400mm*400mm

Economic speed

0-135 piece/min

0-135 piece/min

0-135 piece/min

Gluing accuracy ±1mm

±1mm

±1mm

Power
14kw
14kw 14kw
Dimensions (mm)
13500*2000*2900 13500*2150*2900
13500*2250*2900
Weight
About 5T About 5T About 6T
Face paper thickness
140-800gsm

140-800gsm

140-800gsm

Bottom paper thickness

A/B/C/E/F And four-layer corrugated cardboard
