Five color automatic printing slotting machine

Quantity:
  • Flexographic Printer
  • Manufacturing Plant, Farms, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops
  • Video technical support, Online support, Spare parts, Field maintenance and repair service
  • None
  • None
  • New
  • Letterpress
  • Hebei, China
  • XINGLONG
  • carton printer
  • Automatic
  • Multicolor
  • 380V 50Hz
  • Machine model
  • contact
  • CE
  • 1 YEAR
  • Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Engineers available to service machinery overseas
  • High Productivity
  • Ordinary Product
  • Provided
  • Provided
  • 1.5 years
  • Gear, Engine
  • Carton Box Making
  • Corrugated Paperboard
  • Steel Anilox Roller
  • Steel
  • 1-6 Color
  • High Speed Flexo Printing Machine
  • Printing Carton Box
  • 18
  • Popular Flexo Printing Machine

Five color automatic printing slotting machine


       Function and characteristics:


1. The electric appliance of a whole machine adopt the product of SCHNEIDER made in FRANCE.

2. Adopting helical gear driving, the gears are made from high frequency quenching and polishing-gear.

3. All the axles of roller must be chrome-plating in order to increase the hardness.

4. The gears adopt shower type circular lubricating.

5. This machine adopts PLC touching screen control, adopts frequency Converter,rightly and truly.

6. Automatically changes return zero and correct the plate position.

7. Adopting the mould unit designing, the multi-color printing unit can be combined

   and linked in any way.

8. The side baffle plate of the feeding department and the grooving department are

   adjust by electrically

9. Delivers the paper way to be possible to choose the predestined affinity to deliver the paper system.



Main technology parameter:


Parameter

Model

1300*2000

1300*2200

1300*2400

Max.machinery speed    (pcs/min)

120

Economic printing speed (pcs/min)

100

Max. sheet size              (mm)

1300*2200

1300*2400

1300*2600

Min. sheet size               (mm)

380*500

Min. slotting space         (mm)

160*160*160*160 (Obverse knife)

280*80*280*80     (Reverse knife)

Max. slotting depth        (mm)

320

Max. sheet thickness     (mm)

12

Max. printing area         (mm²)

1300*2000

1300*2200

1300*2400

thickness of standard

printing plate (mm)

6
