Excellent quality press type carton gluer machine

Quantity:
  • Gluing Machine, carton gluer machine
  • New
  • corrugated cardboard
  • Cartons
  • container
  • Semi-Automatic
  • Electric
  • 3-380VAC
  • 3.2 KW
  • Hebei, China
  • XINGLONG
  • XL-press type folder gluer
  • 2300*2500*1300mm
  • About 1.3 T
  • CE
  • Excellent quality press type carton gluer machine
  • Outer
  • 56 meters / sec
  • 1800/2200/2500
  • 1800*1100
  • 200*260
  • Optional
  • 3.2
  • 12 Months
  • Engineers available to service machinery overseas

Excellent quality press type carton gluer machine

Introduction:

The machine is widely used for new development of small orders. It is small in size and easy to operate, and is very suitable for the production of small batch products and the replacement of varieties.

Function and Character:

-Applicable to a wide range of ordinary carton, shaped box single-page molding bonding

-Save glue, the amount of glue is only equivalent to 1/3 of the manual coating

-Save labor, the maximum speed is 56 meters / sec, the efficiency is 3-4 times more than the manual operation

Technological parameter:

Model

JWY-1800

JWY-2200 JWY-2500
Voltage 3-380VAC 3-380VAC 3-380VAC
HZ 50/60 50/60 50/60
Power 3.2KW 3.2KW 3.2KW
Current 7A 7A 7A
Weight 1.3T 1.3T 1.3T
Overall size 2300*2500*1300mm 2300*2900*1300mm 2300*3100*1300mm
Max. size of box 1800*1100mm 2200*1100mm 2500*1100mm
Min. size of box 200*2600mm 200*260mm 200*260mm
