YJE1222
xinglong
Flexo printing machine
:New
Hebei, China
Semi-automatic
printing slotting die cutting machine
XINGLONG
Multicolor
New
customize
Provided
Performance and Characteristics:
1.The machine can finish multi processes one time such as: printing, slotting, creasing, trimming, corner cutting, punching, die cutting, stacking and so on.
2.All of drive rollers are made of high quality steel, hard chrome plated the surface with grinded.
3.Main drive gears adopt high quality steel with heat treatment with clean teeth treatment, adopt cross slip system connect each gear, keep gear fix position, ensure transmission precision.
4.The main drive roller adopt keyless connect, decrease the connection gap, ensure printing precision.
5.The machine adopts sealed spray lubrication for gear system, engineer oil automatic balance device; keep the oil level equal in each unit.
6.The machine adopts lead edge (or kick feeding), low demand for the cardboard, fast.
7.Main motor is VFD, working stability, low power consumption.
Model | YJE920 | YJE1222 | YJE1424 |
Machine inside width (mm) | 2200 | 2400 | 2600 |
Max feeding paper siz(mm) | 900mm*2000mm | 1200mm*2200mm | 1400mm*2400mm |
Max effective printing size(mm) | 900mm*1800mm | 1200mm*2000mm | 1400mm*2200mm |
Min coverage size(mm) | 350mm*720mm | 350mm*720mm | 350mm*720mm |
Max effective die cutting size(mm) | 900mm*1900mm | 1200mm*2100mm | 1400mm*2300mm |
Design speed (pcs/min) | 150pcs/min | 140pcs/min | 120pcs/min |
Working speed (pcs/min) | 130pcs/min | 120pcs/min | 100pcs/min |
Standard Thickness of printing plate | 4-6mm | 4-6mm | 4-6mm |
Printing precision | ±0.5mm | ±0.5mm | ±0.5mm |
Thickness of cardboard | 2-9mm | 2-9mm | 2-9mm |
Wall thickness | 40mm | 40mm | 40mm |
Main motor power | 15kw | 15kw | 15kw |
Lpi of anilox roller | 200/220/250 | 200/220/250 | 200/220/250 |
