Double layers Folder gluer Binding Machine for Corrugated cardboard production line

Availability:
Quantity:
  • 2500

  • xinglong

  • Double Layers Gluer Machine

  • Electric

  • Ordinary Product

  • New

  • China,Hebei

  • Easy to Operate

  • High quality

  • Provided

  • Customized

  • Provided

封面(红)

Double Layers Gluer Machine

涂胶机


1.Machine Function:

* After the glue roller surface quenched,tempered,ground and engraved pit,then doing balancing,making coating evenly, consume less glue

* Glue roller controlled by frequency motor , the inverter control ensures glue line speed is synchronous with double facer, and can also operate independently

* Plc control the glue amount,automatically adjusted according to the production speed Automatic circulation for glue, avoiding glue precipitation

* Pneumatic presses paper structure, adjust the gap by the electric

* Measure the speed signal of the double facer to achieve synchronous operation

* Man-machine interface display, easy to operation

2.Main components:

涂胶机1

3.Machine Technical Parameter:

Working Width

1800-2500mm

Speed

80m-200m/min

Steam Pressure

0.8-1.3Mpa

Glue roller

Φ318mm

Doctor Roller

Φ153mm

Paper roller

Φ86m

Glue rollers frequency motor

5KW

Glue quantity adjustment motor

250W

Motor for adjusting the Gap

250W

Glue pump motor

2.2KW
