Double Facer Machine for 5ply corrugated cardboard production line

  • xinglong

  • Double Facer Machine

  • New

  • Ordinary Product

  • China,Hebei

  • Provided

  • Easy to Operate

  • Provided

  • 1 Year

  • High quality

  • Video Technical Support


WJ150-Double Facer For 5ply corrugated cardboard line


No. Name Qty Feature
1 Hot plate 1

--Main frame is 300 GB channel steel

--Hot plate 600mm 14pcs

2 Cooling part

--5M cooling section

--The upper and lower belt correct automatically

--Temperature display

3 Main drive 1 --Main drive Frequency motor drive
4 High speed belt
1 --Good quality high speed cotton woven belt

1.Machine Description:

* Corrugated paper enter into the double facer hot parts with heating and molding after pasted glue, and  become board after cooling

2.Machine Function:

* Hot Plates width 520mm and 10 pics,cooling parts 4m

* Heat conductive pipe of hot plates control the temperature segmented,with the temperature display

* The inside of the hot plate is partition isolation structure,making the steam flow in S-shaped direction, and the separation function of steam and water is obvious,then improves the steam usage efficiency

* Up belt adopt double cylinder S type  tension device,down belt manual  tension device(small amount adjust)

* Drive rollers’ surface is wrapped by rubber with middle height,to make sure the board output smoothly

* Main drive motor: Variable frequency motor, high force when low speed start, high speed adjusting range, steady to use,easy to mend

* The electrical components adopt international famous brands,  working stably and reliable

3.Machine Technical Parameter

Working Width 1600mm-2200mm
Steam Pressure 0.8-1.3Mpa
Air Pressure
Up Drive Roller


Down Drive Roller


Front Driven Belt Roller


Back Shaping Driven Belt Roller (Down Belt Tension )


Shaping Holder Roller


Note: All the surfaces of the roller are ground and then chromed plated
