Die cutting and creasing machine for corrugated cardboard

Availability:
Quantity:
  • ML1500

  • xinglong

  • Electric

  • Hebei,China

  • Customized

  • 1 Year

  • Customized

  • New

  • Packaging Line

  • Plastic,Wood

  • xinglong

封面 (2)

Die-cutting and Creasing Machine

扪盒机

Applications

     Our die-cutting and creasing machine are available for many materials, such as cardboard, corrugated board, plastic and leather. They are wildly used in printing, package, decoration industry. Our products are sold well in the global due to its high quality and good service.

Functions and Characteristics

     1.Equip with four insurance parts and four functions. The insurance part including gantry insurance, triangle insurance, hand shank insurance and automatic light-operated insurance to makes the machine safety and reliable.

     2.The brake clutch adopts electric suction plate brake clutch to keep the braking sensitive and reliable.

     3. Adjustable template makes the plate loading, unloading more easily.

     4.Three functions including single piece pressing cutting, continuous pressing cutting and time-delay when start machine, the delay time  can be adjusted, the time can be adjusted from 0.1s to 9.9s.

Advantages

     1.Our die cut machine is manufactured using high quality material for high strength.Strengthened construction ensures smooth operation and long service life.

     2.It adopts world famous brand electrical components,such as Schneider.
     3. Our die cutting machine uses centralized lubrication pump system.


Model

Max.Rule Area(mm)

Working speed(stroes/min)

Wacrulelength

Molor

Weight

Overall Dimensions(LxWxH)

ML750

750x520

28±2

<15m

2.2KW

2000kg

1260x1350x1280mm

ML930

930x670

23±2

<25m

4.0KW

3000kg

1800x1600x1600mm

ML1100

1100x800

20±2

<32m

5.5KW

4000kg

1900x1800x1700mm

ML1200

1200x830

20±2

<35m

5.5KW

4300kg

1900x2000x1700mm

ML1300

1300x920

18±2

<40m

5.5KW/7.5KW

5300kg

2000x2400x1800mm

ML1400

1400x1000

18±2

<45m

5.5KW/7.5KW

6000kg

2000x2450x1900mm

ML1500

1500x1050

18±2

<45m

5.5KW/7.5KW

6500kg

2000x2500x1930mm

ML1500

1500x1150

18±2

<45m

5.5KW/7.5KW

6800kg

2000x2500x1980mm

ML1600

1600x1250

16±2

<50m

11KW

11000kg

2170x2560x2130mm

ML1800

1800x1300

16±2

<62m

15KW

13500kg

2240x2800x2230mm

ML2000

2000x1400

16±2

<80m

15KW

14500kg

2280x2900x2230mm

ML2200

2200x1450

16±2

<90m

18KW

16500kg

2280x3000x2250mm

ML2500

2500x1600

13±2

<95m

22KW

20000kg

3580x2400x255mm
