DXJ-1200
xinglong
Manual stitching machine
Ordinary Product
China,Hebei
New
Manual
1 Year
1 Year
Customized
Video Technical Support
Easy to Operate
DXJ Series Manual Box Stitching Machine
Machine Introduction
The DXJ Box stitching machine adopts double eccentric wheel structure, pressure angle used suitable cutter point. The interchangeability assembling parts adopt rolling bearing so machine run more stable and faster, stitch fixable, long time use life.
Main Technology Parameters
Model | DXJ-1200 | DXJ-1400 |
Arm effective length | 1200mm | 1400mm |
Total height | 1650mm | 1650mm |
Seat length | 1000mm | 1200mm |
Stitching speed | 250times/min | 250times/min |
Stitching thickness | 3ply, 5ply, 7ply | 3ply, 5ply, 7ply |
Applicable stitching wire | 1.80mm*0.59mm(w*h) | 1.80mm*0.59mm(w*h) |
Motor power | 0.37kw | 0.37kw |
Weight | 450kg | 500kg |
Dimension | 1600×600×1650mm (L×W×H) | 1800×600×1650mm (L×W×H) |
DXJ Series Manual Box Stitching Machine
Machine Introduction
The DXJ Box stitching machine adopts double eccentric wheel structure, pressure angle used suitable cutter point. The interchangeability assembling parts adopt rolling bearing so machine run more stable and faster, stitch fixable, long time use life.
Main Technology Parameters
Model | DXJ-1200 | DXJ-1400 |
Arm effective length | 1200mm | 1400mm |
Total height | 1650mm | 1650mm |
Seat length | 1000mm | 1200mm |
Stitching speed | 250times/min | 250times/min |
Stitching thickness | 3ply, 5ply, 7ply | 3ply, 5ply, 7ply |
Applicable stitching wire | 1.80mm*0.59mm(w*h) | 1.80mm*0.59mm(w*h) |
Motor power | 0.37kw | 0.37kw |
Weight | 450kg | 500kg |
Dimension | 1600×600×1650mm (L×W×H) | 1800×600×1650mm (L×W×H) |
