Corrugated Carton Box Making Flexo Printing Cutting Slotting Machine Prices

Quantity:
  • Other
  • 1 YEAR, 1year
  • Manufacturing Plant, Food & Beverage Factory, Farms, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops
  • Video technical support, Online support, Spare parts, Field maintenance and repair service
  • None
  • None
  • New
  • Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
  • Cartons, Film, Case
  • Paper, Plastic, Wood
  • Automatic
  • Electric
  • 380V/50HZ 3PHASE
  • 22kw
  • Hebei, China
  • XINGLONG
  • 20000KG
  • 1200*3200 *2000mm
  • CE Certificate
  • Field installation, commissioning and training, Engineers available to service machinery overseas
  • Energy saving
  • die cutter for corrugated cardboard
  • Optional
  • 80-120

Corrugated Carton Box Making Flexo Printing Cutting Slotting Machine Prices



Performance

1. YJ-130 type automatic carton flexo printer slotting die cutting machine is ecnomic type machine for medium-sized factories.
2.     The machine adopts lead edge feeder with suction, feed board smooth and no damage , low demand for the cardboard, save workers.
3. control syste: PLC with touch screen set cylinder vertical adjusting automaticallly, memory order and change automatically, igreatly improve production effciency
4. this printing machine can combind with slotting unit or rotary die cutter, vibrator and stacker.  make carton box one time.
5. Frequency drive motor, working stability, low power consumption.
6. The machine adopts sealed spray lubrication for gear system, engineer oil automatic balance device; keep the oil level equal ineach unit.
7. Grinded 45# steel gear, low nosie and long use life.

Main Technology parameters:

Model

YJ250-1022

YJ220-1224

YJ200-1426

Machine inside width (mm)

2400

2600

2800

Max feeding paper size(mm)

1000*2200

1200*2400

1400*2600

Max effective printing size(mm)

1000*2000

1200*2200

1400*2400

Min coverage size(mm)

400*600

400*600mm

400*600

Design speed(pcs/min)

250

220pcs/min

200

Working speed(pcs/min)

210-230

180-200pcs/min

160-180

Standard Thickness of printing plate

6mm

6mm

6mm

Printing precision

±0.5mm

±0.5mm

±0.5mm

Thickness of cardboard

1.2-9mm

1.2-9mm

1.2-9mm

Wall thickness

50mm

50mm

50mm

Main motor power

About 18kw

About 18kw

About 18kw
