New
Paper Cutting Machine
Yes
Hebei, China
XINGLONG
XL-slitter scorer
380V 50Hz
20.25KW
4380*1350*2340mm
6tons
CE Certificate
China professional digital cutter flatbed machine
XL-cutting machine
Optional Color
200m/min
150pcs/min
2550mm
135mm
<±0.5mm
4 blades 6 scorers or 5 blades 8 scorers
one year, 1 Year
Engineers available to service machinery overseas
China professional digital cutter flatbed machine
Technical Parameter:
Type | NCFY1800 | NCFY2000 | NCFY2200 | NCFY2500 |
Slitter | 5-7 blades | 5-7 blades | 5-7 blades | 5-7 blades |
Scorer | 8-12 scores | 8-12 scores | 8-12 scores | 8-12 scores |
Max. Slitting Width | 1850mm | 2050mm | 2250mm | 2550mm |
Min. Slitting Width | 135mm | 135mm | 135mm | 135mm |
Min. Scoring Width | ||||
Common | 128mm | 128mm | 128mm | 128m |
0 Scoring | 0mm | 0m | 0mm | 0mm |
Max. Line Speed | 200m/min | 200m/min | 200m/min | 200m/min |
Machine size(mm) | ||||
Common | 3680*1350*2340 | 3880*1350*2340 | 4080*1350*2340 | 4380*1350*2340 |
0 Scoring | 3680*1680*2340 | 3880*1680*2340 | 4080*1680*2340 | 4380*1680*2340 |
General Motor Power | 16.25KW | 16.25KW | 20.25KW | 20.25KW |
Features:
-High quality industry computer and PLC equipped composing the CNC system
-High quality linear guide and high precision ball screw system guarantee the slitting and scoring accuracy in 0.50mm.
-A memory of 999 orders, non-stop changeover or manual changeover can be realized.
-Automatic synchronize with the corrugator and can also get in line with manufacture management system.
-Quick changeover within 3 to 8 seconds.
If you are also interested in the following product, please click the link
1. Q: Are you a manufacturer, trading company or a third party?
A: We are a manufacturer, located in Mahai industrial area south of Dongguang county, Hebei province, China. Warmly welcome to visit our company.
2. Q: What is your minimum order quantity, can you send me samples?
A: Our minimum quantity is 1 set, as our product is machinery equipment, it’s difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.
3. Q: How does your factory do regarding quality controlling?
A: 1) All raw material we used are environmental-friendly
2) Skillful workers care every details in handling the producing and packing process
3) Quality control department are specially responsible for quality in each process
We have been kept providing high quality products by introducing advanced technologies for over 20 years, and our products are also widely exported to many different countries including Russia, the Middle East, Africa, Southeast Asia, EU, etc, which earned us a high reputation among the customers.
4. Q: What is the delivery time of your machine?
A: In general, the delivery time of our machine is about 30 days, customized machine will be delivered as the negotiation with our clients.
5. Q: How about the after-sale service?
A: 1) TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.
2) To solve the problems with videos/pictures.
3) One year warranty for spare parts change.
If you meet any other questions, please feel free to contact us. click here
