BA Semi-automatic Printing Slotting Die Cutting Machine

1. Semi-automatic printing slotting die cutting machine used for corrugated cardboard production and processing,Adopt flexographic water-ink printing process.It costs less than printing ink.
2. This machine consist of paper feeder unit, printing unit,slotting unit(option) and die-cutting unit(option),It can finish multi processes one time such as: printing, slotting, save labor costs.
3. This machine adopts chain feeding system, side gauge positioning board,speed is adjustable.
4. All of drive rollers are made of high quality steel,the surface be grinded,hard chrome plated.
5. Printing register adopt planet style electrical adjustment of 360 degrees whatever operating and stopping, quickly and accurately.
6.Motorized shift and pneumatic locking up of printing units.
Quantity:
  • BA410-2300
  • XINGLONG

Feeding unit

微信图片_201907021052312

nChain table artificial feeding paper

nThere are four gear chain bars, and each file has three cross-stack cardboard.

nAbrasion resistance materials as the support of the bottom of chains, fast running, low noise .

nEquipped with block paper steel bar to ensure the easy feeding of the bend cardboard.



Printing unit

微信图片_201907021052313


n  Printing roller, paper feeding roller, pressure roller adopt high quality thick wall seamless steel tube,all the surfaces grinding, hard chromium plating

n  High quality steel 200mesh or 200mesh combination, can print 45line flexographic plate.

n  Good wear resisting, oil resistance, acid-proof alkali rubber, design medium to high grinding, ink transfer effect is good.

n  The printing roller pressure adjust by the gear adjustment without clearance, the printing roller pressure can reach the best printing state.

n  360 degree electric phase, adopt CPU computer digital control device, according to the error input the data, it can automatic adjust phase, printing electric power adjusting mechanism adopt planetary gears working,  at non-stop condition, can 360degree random adjust,  the axial adjustment by manual, adjustable distance is 30mm, the machine turns or stop can be operated.

n  Motorized shift and pneumatic locking up of printing units.

n Inking roller can be detached from printing plate automatically to avoid damage the printing plate.

n  Inking roller equipped idling running device to prevent ink from being dried when machine stop.

n  Pneumatic lifting and down the anilox roller, auto ink distributing.


Slotting unit

开槽部


n  The slotting knives pedestal can be worm-type adjustment according to the thickness of card board. ( Three & Five layer only).

n  The slitting knives pedestal can be worm-type adjustment according to the thickness of card board. ( Three & Five layer only).

n  The back slotting knife (Height of the box) Four knives adjustment synchronous, easy working.

n  7mm alloy steel slotting knives with indent heat treatment to enable grinding teeth sharp edge.


Main Technology Parameter:



Model

BA480-2300

BA480-2600

BA480-2800

 Machine inside width

2300mm

2600mm

2800mm

Paper coverage area

1450×2100

1450×2400

1450×2600

Effective printing area

1450*2000mm

1450*2300mm

1450*2500mm

Min paper coverage area

350×500mm

350×500mm

350×500mm

Standard Thickness of printing plate

6mm

6mm

6mm

Working speed

about   0-60sheets

about   0-60sheets

about   0-60sheets

Printing precision

  ±0.5mm

  ±0.5mm

  ±0.5mm

Thickness of cardboard

  1.2-9mm

  1.2-9mm

  1.2-9mm

Main power






424
