| Quantity: | |
|---|---|
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use
Video technical support, Online support, Spare parts, Field maintenance and repair service
None
None
New
corrugated cardboard
Corrugated cardboard production
Hebei, China
XINGLONG
220V/380V
90-130kw
carton machine size customized
about 120Tons
CE
150 pcs/min
Provided
Provided
Ordinary Product
1 YEAR
Engine, Gear
Engineers available to service machinery overseas
Automated corrugated cardboard box making machine
Optional
Corrugated cardboard production line/paper carton making machine
Container
60-220m/min
1200-2200mm
Steam, electric, thermal oil
90-130kw
One year, 1 Year
Main units:
No. | Name | Sets | Comment |
1 | Mill roll stand |
| Electric mill roll stand , expansion dop top, pneumatioc brake |
2 | Single facer |
| vac-sorb,φ320 alloy roller ,cardan drive |
3 | Feeding paper bridge |
| Electric adjust deviation,adsorb tension |
4 | Second gluing machine |
| Conversion synchronous control |
5 | Triply pre-heater |
| φ 800,electric wrap angle (including qualification certificate ) |
6 | pre-heater |
| φ 800,land type electric wrap angle (including qualification certificate ) |
7 | Dry formed part |
| 520mm×18 pieces hot plate ,adopt Adopt up and down intensive roller(including qualification certificate ) |
8 | Heat formed part |
| Adopt up and down intensive roller ,length 8m |
9 | Feeding paper belt |
| High quality carton belt , electric promote |
10 | Thin blade slitter scorer machine |
| 5 blade 8 line , electric Correct error , alloy blade |
11 | Corss cutter |
| Computer control cutting cardboard length 500-9999mm; cutting cardboard precision ±1mm |
12 | Main drive |
| Main power 25KW |
13 | Make paste system |
| Barrel type ,electric stir circulate glue design |
14 | Stand feeding paper car |
| Include slipping way |
15 | Pump |
| Electric aeration |
16 | Electric system |
| One Operate cabinet ,one sinlge facer 1 main drive |
17 | Steam system |
| Not including heat source and pipe |
18 | Gantry stacker |
| Belt drive type |
1. Q: Are you a manufacturer, trading company or a third party?
A: We are a manufacturer, located in Mahai industrial area south of Dongguang county, Hebei province, China. Warmly welcome to visit our company.
2. Q: What is your minimum order quantity, can you send me samples?
A: Our minimum quantity is 1 set, as our product is machinery equipment, it’s difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.
3. Q: How does your factory do regarding quality controlling?
A: 1) All raw material we used are environmental-friendly
2) Skillful workers care every details in handling the producing and packing process
3) Quality control department are specially responsible for quality in each process
We have been kept providing high quality products by introducing advanced technologies for over 20 years, and our products are also widely exported to many different countries including Russia, the Middle East, Africa, Southeast Asia, EU, etc, which earned us a high reputation among the customers.
4. Q: How about the after-sale service?
A: 1) TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.
2) To solve the problems with videos/pictures.
3) One year warranty for spare parts change.
Contact for professional service. Contact Us
